ABUS 24IB Series Stainless Steel Diskus Discus Padlock

From
£77.90
Select size, finish, and quantity from the variant table.
View options

The ABUS 24IB Series Stainless Steel Diskus Padlock is a marine-grade security solution designed to provide ultimate protection in harsh, corrosive environments. Made in Germany, this padlock features a 100% rust-free construction with a high-quality stainless steel shackle, body, and internal components.

The ABUS 24IB Series Stainless Steel Diskus Padlock is a marine-grade security solution designed to provide ultimate protection in harsh, corrosive environments. Made in Germany, this padlock features a 100% rust-free construction with a high-quality stainless steel shackle, body, and internal components.

Its iconic 360° Diskus design offers exceptional resistance to physical attacks, particularly forcing and cutting, by leaving only a tiny portion of the shackle exposed. For added security, it incorporates an anti-cut plate and a precision pin tumbler cylinder with anti-pick mushroom pins. A fitted anti-dust cap protects the cylinder from dirt and moisture, ensuring smooth operation even in coastal or outdoor conditions.

This padlock is available in multiple body widths (60mm or 71mm), shackle diameters (8mm or 10mm), and keying options (Keyed Alike or Keyed To Differ). Please choose your preferred size, clearance, and keying configuration from the options below.

Technical Specifications

  • Body Width: 60mm or 71mm (please choose from the options below)
  • Body Height: 60mm or 71mm (please choose from the options below)
  • Body Depth: 26mm or 31mm (please choose from the options below)
  • Shackle Diameter: 8mm or 10mm (please choose from the options below)
  • Horizontal Clearance: 17.5mm or 19.5mm (please choose from the options below)
  • Vertical Clearance: 13mm or 17mm (please choose from the options below)
  • Shackle Finish: Stainless Steel
  • Keying Options: Keyed Alike or Keyed To Differ (please choose from the options below)
  • Key Retaining: Yes
  • Keys Supplied: 2 keys
  • Weather Resistant: Yes (marine grade)
  • Weight: 208g to 321g (please choose from the options below)

Key Features

  • Rust-Free Security: 100% rust-free construction with stainless steel shackle, case, and internal parts designed for marine environments
  • 360° Diskus® Design: Iconic shape protects against common forcing methods by leaving minimal shackle exposed
  • Deep Weld Technology: Diskus deep welding provides maximum case strength and durability
  • Anti-Cut Protection: Integrated anti-cut plate offers genuine all-round protection
  • Anti-Pick Cylinder: Precision pin tumbler cylinder with anti-pick mushroom pins
  • Weather Protection: Fitted anti-dust cap protects the cylinder from dirt and moisture damage
  • Key Retaining: Key retaining feature ensures the lock is securely closed before the key can be removed
Variant image
L19011 Ref: 24IB/70 C
£ 94.34
  • Part No.: L19011
  • Manufacturer Reference: 24IB/70 C
  • Barcode: 4003318350443
  • Body Depth: 31mm (More)
  • Body Height: 71mm (More)
  • Body Width: 71mm (More)
  • Boxed Quantity: 6 (More)
  • Brand: Abus (More)
  • Horizontal Clearance: 19.5mm (More)
  • Key Retaining: Yes
  • Key Series: 12874 (More)
  • Keyed: Keyed To Differ (More)
  • Keying - KA: Stocked
  • Keys Supplied: 2 (More)
  • Pack Quantity: 1
  • Packaging: Visi
  • Shackle Diameter: 10mm (More)
  • Shackle Finish: Stainless Steel (More)
  • Silca Card Code: 500 (More)
  • Vertical Clearance: 17mm (More)
  • Weather Resistant: Yes
  • Weight: 321g (More)
Variant image
L19012 Ref: 24IB/60
£ 77.90
  • Part No.: L19012
  • Manufacturer Reference: 24IB/60
  • Barcode: 4003318055843
  • Body Depth: 26mm (More)
  • Body Height: 60mm (More)
  • Body Width: 60mm (More)
  • Boxed Quantity: 6 (More)
  • Brand: Abus (More)
  • Horizontal Clearance: 17.5mm (More)
  • Key Retaining: Yes
  • Key Series: 2706 (More)
  • Keyed: Keyed To Differ (More)
  • Keying - KA: Stocked
  • Keys Supplied: 2 (More)
  • Pack Quantity: 1
  • Packaging: Boxed
  • Shackle Diameter: 8mm (More)
  • Shackle Finish: Stainless Steel (More)
  • Silca Card Code: 500 (More)
  • Vertical Clearance: 13mm (More)
  • Weather Resistant: Yes
  • Weight: 208g (More)
Variant image
L19013 Ref: 24IB/70
£ 91.26
  • Part No.: L19013
  • Manufacturer Reference: 24IB/70
  • Barcode: 4003318020506
  • Body Depth: 31mm (More)
  • Body Height: 71mm (More)
  • Body Width: 71mm (More)
  • Boxed Quantity: 6 (More)
  • Brand: Abus (More)
  • Horizontal Clearance: 19.5mm (More)
  • Key Retaining: Yes
  • Key Series: 12874 (More)
  • Keyed: Keyed To Differ (More)
  • Keying - KA: Stocked
  • Keys Supplied: 2 (More)
  • Pack Quantity: 1
  • Packaging: Boxed
  • Shackle Diameter: 10mm (More)
  • Shackle Finish: Stainless Steel (More)
  • Silca Card Code: 500 (More)
  • Vertical Clearance: 17mm (More)
  • Weather Resistant: Yes
  • Weight: 307g (More)
Variant image
L19014 Ref: 24IB/60 KA EE0036
£ 85.70
  • Part No.: L19014
  • Manufacturer Reference: 24IB/60 KA EE0036
  • Barcode: 4003318457470
  • Body Depth: 26mm (More)
  • Body Height: 60mm (More)
  • Body Width: 60mm (More)
  • Boxed Quantity: 6 (More)
  • Brand: Abus (More)
  • Horizontal Clearance: 17.5mm (More)
  • Key Retaining: Yes
  • Key Series: 2706 (More)
  • Keyed: Keyed Alike (More)
  • Keying - KA: Stocked
  • Keys Supplied: 2 (More)
  • Notes: Keyed Alike - 45747 (More)
  • Pack Quantity: 1
  • Packaging: Boxed
  • Shackle Diameter: 8mm (More)
  • Shackle Finish: Stainless Steel (More)
  • Silca Card Code: 500 (More)
  • Vertical Clearance: 13mm (More)
  • Weather Resistant: Yes
  • Weight: 216g (More)
Variant image
L19015 Ref: 24IB/60 KA EE0113
£ 85.70
  • Part No.: L19015
  • Manufacturer Reference: 24IB/60 KA EE0113
  • Barcode: 4003318325021
  • Body Depth: 26mm (More)
  • Body Height: 60mm (More)
  • Body Width: 60mm (More)
  • Boxed Quantity: 6 (More)
  • Brand: Abus (More)
  • Horizontal Clearance: 17.5mm (More)
  • Key Retaining: Yes
  • Key Series: 2706 (More)
  • Keyed: Keyed Alike (More)
  • Keying - KA: Stocked
  • Keys Supplied: 2 (More)
  • Notes: Keyed Alike - 32502 (More)
  • Pack Quantity: 1
  • Packaging: Boxed
  • Shackle Diameter: 8mm (More)
  • Shackle Finish: Stainless Steel (More)
  • Silca Card Code: 500 (More)
  • Vertical Clearance: 13mm (More)
  • Weather Resistant: Yes
  • Weight: 216g (More)
Variant image
L19017 Ref: 24IB/60 KA EE0140
£ 85.70
  • Part No.: L19017
  • Manufacturer Reference: 24IB/60 KA EE0140
  • Barcode: 4003318325052
  • Body Depth: 26mm (More)
  • Body Height: 60mm (More)
  • Body Width: 60mm (More)
  • Boxed Quantity: 6 (More)
  • Brand: Abus (More)
  • Horizontal Clearance: 17.5mm (More)
  • Key Retaining: Yes
  • Key Series: 2706 (More)
  • Keyed: Keyed Alike (More)
  • Keying - KA: Stocked
  • Keys Supplied: 2 (More)
  • Notes: Keyed Alike - 32505 (More)
  • Pack Quantity: 1
  • Packaging: Boxed
  • Shackle Diameter: 8mm (More)
  • Shackle Finish: Stainless Steel (More)
  • Silca Card Code: 500 (More)
  • Vertical Clearance: 13mm (More)
  • Weather Resistant: Yes
  • Weight: 216g (More)
Variant image
L19018 Ref: 24IB/70 KA EE0113
£ 100.36
  • Part No.: L19018
  • Manufacturer Reference: 24IB/70 KA EE0113
  • Barcode: 4003318325281
  • Body Depth: 31mm (More)
  • Body Height: 71mm (More)
  • Body Width: 71mm (More)
  • Boxed Quantity: 6 (More)
  • Brand: Abus (More)
  • Horizontal Clearance: 19.5mm (More)
  • Key Retaining: Yes
  • Key Series: 12874 (More)
  • Keyed: Keyed Alike (More)
  • Keying - KA: Stocked
  • Keys Supplied: 2 (More)
  • Notes: Keyed Alike - 32528 (More)
  • Pack Quantity: 1
  • Packaging: Boxed
  • Shackle Diameter: 10mm (More)
  • Shackle Finish: Stainless Steel (More)
  • Silca Card Code: 500 (More)
  • Vertical Clearance: 17mm (More)
  • Weather Resistant: Yes
  • Weight: 313g (More)
Review variants and add to basket when ready.
