Ifam U Series Brass Padlocks

<b>Ifam U Series Brass Padlocks</b>

Click image to enlarge
Click here to email this image

<b>Ifam U Series Brass Padlocks</b>
<b>Ifam U Series Brass Padlocks</b>
<b>Ifam U Series Brass Padlocks</b>

Brass shutter padlocks with hardened shackles available keyed alike and to differ.

Extra keys are available with your order at the top of the list, ideal for customers who need lots of extra keys IE Sports clubs & schools.

Exc VAT from: £19.37
Inc VAT from: £23.25


 U70 padlock U90 padlock
Body base (A) 70mm 90mm
 Body height (B) 55mm 64.5mm
 Shackle height (C) 15.5mm 17.5mm
 Shackle diameter (D) 12mm12mm
 Distance from the padlock base to the shackle base (E) 24mm31.4mm
 Body thickness (F) 20mm20mm
 Shackle span (M) 22mm36mm
 Padlock?s large flap?s length (N) 34mm34mm
 Padlock?s short flap?s length (L) 14mm20mm


Opening / locking: Ball bearing locking system. Key retention system when the padlock is open.


  • 2 keys
  • Key retaining
  • Automatic locking
  • Key opposite end to bolt
  • Solid extruded brass body with carbon nitride hardened shackle
  • Ball bearing locking mechanism
  • Key at the opposite end to the pin
  • Keyed alike versions on ongoing numbers


  • Visi-packed
  • Boxed for keyed aliked version
Part Number Description Body WidthPackaging Exc VAT Inc VAT Qty Add
IF00770 Key to differ 70mm Visi packed £19.37 £23.25
- + Add
IF00790 Key to differ 90mm Visi packed £26.84 £32.21
- + Add
